ONELASER CUTTER & ENGRAVING SETTINGS FOR DIFFERENT MATERIALS

Unlock the full potential of your OneLaser Machine with optimized settings for various materials.

38W (RF)

55W (CO2)

80W (CO2)

100W (CO2)

130W (CO2)

150W(CO2)

Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Plywood
/ Engraving 1000 50 50 low 350
3mm Cutting 10 90 90 high 1.5"
6mm Cutting 5 90 90 high 1.5"
10mm Cutting 5 90 90 high 2"
15mm Cutting x x x x 1.5"
18mm Cutting x x x x 1.5"
Cherry Wood
/ Engraving 500 10 38 low 300
3mm Cutting 20 90 90 high 1.5"
8mm Cutting 6 90 90 high 2"
11mm Cutting 4 90 90 high 2"
15mm Cutting x x x x 1.5"
20mm Cutting x x x x 1.5"
MDF
/ Engraving 1000 50 50 low 350
3mm Cutting 20 90 90 high 1.5"
10mm Cutting x x x x 1.5"
15mm Cutting x x x x 1.5"
20mm Cutting x x x x 1.5"
Acrylic
/ Engraving 1000 50 50 low 350
3mm Cutting 15 90 90 high 1.5"
5mm Cutting 5 90 90 high 1.5"
10mm Cutting 2 90 90 high 1.5"
15mm Cutting x x x x 1.5"
20mm Cutting x x x x 1.5"
EVA Foam
/ Engraving 1000 10 10 low 350
10mm Cutting 20 90 90 high 1.5"
20mm Cutting x x x x 1.5"
30mm Cutting x x x x 1.5"
Cork
/ Engraving 1000 20 20 low 350
3mm Cutting 60 90 90 high 1.5"
Bamboo
/ Engraving 1000 60 60 low 350
3mm Cutting 7 90 90 high 1.5"
Cotton Fabric
/ Engraving 1000 40 40 low 350
1mm Cutting 160 90 90 high 1.5"
3mm Cutting 140 90 90 high 1.5"
Cardboard
/ Engraving 1000 50 50 low 350
3mm Cutting 15 90 90 high 1.5"
4mm Cutting 4 90 90 high 1.5"
Leatherette
/ Engraving 1000 50 50 low 350
1.5mm Cutting 20 90 90 high 1.5"
3mm Cutting 5 90 90 high 1.5"
Denim
/ Engraving 1000 20 20 low 350
1mm Cutting 150 90 90 high 1.5"
3mm Cutting x x x x 1.5"
5mm Cutting x x x x 1.5"
Rubber
/ Stamp Engraving 150 25 80 high 400
2.3mm Cutting 10 90 90 high 1.5"
Delrin
/ Engraving 1000 20 20 low 350
1mm Cutting 45 90 90 high 1.5"
3mm Cutting 5 90 90 high 1.5"
5mm Cutting 3 90 90 high 1.5"
Melamine
/ Engraving 1000 50 50 low 350
1mm Cutting 4 90 90 high 1.5"
Paper
/ Engraving 1000 5 5 low 350
0.6mm Cutting 200 90 90 high 1.5"
Mylar
/ Engraving 1000 90 90 low 350
1.5mm Cutting 15 90 90 high 1.5"
Anodized Aluminum
/ Engraving 1000 50 50 low 350
Powdercoated Tumblers
/ Engraving 1000 60 60 low 350
Ceramic
/ Engraving 1000 60 60 low 350
Glass
/ Engraving 1000 50 50 low 350
Marble
/ Marble 1000 40 40 low 350
Slate
/ Marble 1000 50 50 low 350
Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Birch Ply
/ Engraving 500 10 30 low 300
3mm Cutting 40 10 90 high 2"
6mm Cutting 8 10 90 high 2"
10mm Cutting 5 10 90 high 2"
15mm Cutting x 10 90 high 4"
18mm Cutting x 10 90 high 4"
Cherry Wood
/ Engraving 500 10 42 low 300
3mm Cutting 51 10 90 high 2"
8mm Cutting 5 10 90 high 2"
11mm Cutting 2 10 90 high 4"
15mm Cutting x 13 90 high 4"
20mm Cutting x 10 90 high 4"
MDF
/ Engraving 500 10 22 low 300
3mm Cutting 21 10 90 high 2"
10mm Cutting 2 10 90 high 2"
15mm Cutting x 10 90 high 4"
20mm Cutting x 15 90 x 4"
Acrylic
/ Engraving 500 10 42 low 300
3mm Cutting 32 10 90 high 2"
5mm Cutting 10 10 90 high 2"
10mm Cutting 1 10 90 high 2"
15mm Cutting x 10 90 high 4"
20mm Cutting x 10 90 high 4"
EVA Foam
/ Engraving 500 13 15 low 300
10mm Cutting 40 10 90 high 2"
20mm Cutting 17 10 90 high 4"
30mm Cutting 4 10 90 high 4"
Cork
/ Engraving 500 13 30 low 300
3mm Cutting 152 10 90 high 2"
Bamboo
/ Engraving 500 10 42 low 300
5mm Cutting 7 10 90 high 2"
Cotton Fabric
/ Engraving 500 10 42 low 300
1mm Cutting 295 10 90 high 2"
3mm Cutting 295 10 90 high 2"
Cardboard
/ Engraving 500 10 22 low 300
3mm Cutting 25 10 90 high 2"
4mm Cutting 17 10 90 high 2"
Leatherette
/ Engraving 500 10 42 low 300
1.5mm Cutting 58 10 90 high 2"
3mm Cutting 23 10 90 high 2"
Denim
/ Engraving 500 13 15 low 300
1mm Cutting 295 10 90 high 2"
Rubber
/ Stamp Engraving 200 25 110 high 400
2.3mm Cutting 21 10 90 high 2"
Delrin
/ Engraving 500 10 55 low 300
1mm Cutting 95 10 90 high 2"
3mm Cutting 10 10 90 high 2"
5mm Cutting 4 10 90 high 2"
Fiberglass
/ Engraving 500 x x x 300
1mm Cutting 1 10 90 high 2"
Melamine
/ Engraving 500 10 42 low 300
1mm Cutting 21 10 90 high 2"
Mother of Pearl
/ Engraving 500 10 70 low 300
3mm Cutting 70 10 90 high 2"
Paper
/ Engraving 500 10 30 low 300
0.6mm Cutting 295 10 90 high 2"
Mylar
/ Engraving 500 25 30 low 300
1.5mm Cutting 47 10 90 high 2"
Anodized Aluminum
/ Engraving 500 10 45 low 300
Powdercoated Tumblers
/ Engraving 300 10 50 low 350
Ceramic
/ Engraving 500 10 98 low 300
Glass
/ Engraving 500 10 110 low 300
Marble
/ Engraving 500 10 45 low 300
Slate
/ Engraving 500 10 55 low 300
Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Birch Ply
/ Engraving 500 10 20 low 300
3mm Cutting 50 10 90 high 2"
6mm Cutting 15 10 90 high 2"
10mm Cutting 10 10 90 high 2"
15mm Cutting 1 10 90 high 4"
18mm Cutting x 10 90 high 4"
Cherry Wood
/ Engraving 500 10 30 low 300
3mm Cutting 75 10 90 high 2"
8mm Cutting 10 10 90 high 2"
11mm Cutting 8 10 90 high 4"
15mm Cutting 3 10 90 high 4"
20mm Cutting 1 10 90 high 4"
MDF
/ Engraving 500 10 20 low 300
3mm Cutting 35 10 90 high 2"
10mm Cutting 8 10 90 high 2"
15mm Cutting 2 10 90 high 4"
20mm Cutting x 10 90 x 4"
Acrylic
/ Engraving 500 10 30 low 300
3mm Cutting 50 10 90 high 2"
5mm Cutting 20 10 90 high 2"
10mm Cutting 5 10 90 high 2"
15mm Cutting 1 10 90 high 4"
20mm Cutting x 10 90 high 4"
EVA Foam
/ Engraving 500 10 10 low 300
10mm Cutting 60 10 90 high 2"
20mm Cutting 30 10 90 high 4"
30mm Cutting 10 10 90 high 4"
Cork
/ Engraving 500 10 20 low 300
3mm Cutting 210 10 90 high 2"
Bamboo
/ Engraving 500 10 30 low 300
5mm Cutting 18 10 90 high 2"
Cotton Fabric
/ Engraving 500 10 30 low 300
1mm Cutting 300 10 90 high 2"
3mm Cutting 300 10 90 high 2"
Cardboard
/ Engraving 500 10 20 low 300
3mm Cutting 40 10 90 high 2"
4mm Cutting 30 10 90 high 2"
Leatherette
/ Engraving 500 10 30 low 300
1.5mm Cutting 90 10 90 high 2"
3mm Cutting 40 10 90 high 2"
Denim
/ Engraving 500 10 10 low 300
1mm Cutting 300 10 90 high 2"
Rubber
/ Stamp Engraving 200 25 80 high 400
2.3mm Cutting 35 10 90 high 2"
Delrin
/ Engraving 500 10 40 low 300
1mm Cutting 130 10 90 high 2"
3mm Cutting 20 10 90 high 2"
5mm Cutting 8 10 90 high 2"
Fiberglass
/ Engraving 500 x x x 300
1mm Cutting 2 10 90 high 2"
Melamine
/ Engraving 500 10 30 low 300
1mm Cutting 35 10 90 high 2"
Mother of Pearl
/ Engraving 500 10 50 low 300
3mm Cutting 100 10 90 high 2"
Paper
/ Engraving 500 10 20 low 300
0.6mm Cutting 300 10 90 high 2"
Mylar
/ Engraving 500 20 20 low 300
1.5mm Cutting 70 10 90 high 2"
Anodized Aluminum
/ Engraving 500 10 40 low 300
Powdercoated Tumblers
/ Engraving 500 10 50 low 300
Ceramic
/ Engraving 500 10 70 low 300
Glass
/ Engraving 500 10 80 low 300
Marble
/ Engraving 500 10 40 low 300
Slate
/ Engraving 500 10 40 low 300
Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Birch Ply
/ Engraving 500 10 15 low 300
3mm Cutting 52 10 90 high 2"
6mm Cutting 20 10 90 high 2"
10mm Cutting 13 10 90 high 2"
15mm Cutting 2 10 90 high 4"
18mm Cutting 1 10 90 high 4"
Cherry Wood
/ Engraving 500 10 25 low 300
3mm Cutting 80 10 90 high 2"
8mm Cutting 13 10 90 high 2"
11mm Cutting 10 10 90 high 4"
15mm Cutting 6 8 90 high 4"
20mm Cutting 3 10 90 high 4"
MDF
/ Engraving 500 10 20 low 300
3mm Cutting 40 10 90 high 2"
10mm Cutting 10 10 90 high 2"
15mm Cutting 3 10 90 high 4"
20mm Cutting x 5 90 x 4"
Acrylic
/ Engraving 500 10 20 low 300
3mm Cutting 55 10 90 high 2"
5mm Cutting 25 10 90 high 2"
10mm Cutting 6 10 90 high 2"
15mm Cutting 2 10 90 high 4"
20mm Cutting 1 10 90 high 4"
EVA Foam
/ Engraving 500 8 8 low 300
10mm Cutting 65 10 90 high 2"
20mm Cutting 33 10 90 high 4"
30mm Cutting 13 10 90 high 4"
Cork
/ Engraving 500 8 13 low 300
3mm Cutting 225 10 90 high 2"
Bamboo
/ Engraving 500 10 25 low 300
5mm Cutting 21 10 90 high 2"
Cotton Fabric
/ Engraving 500 10 20 low 300
1mm Cutting 300 10 90 high 2"
3mm Cutting 300 10 90 high 2"
Cardboard
/ Engraving 500 10 20 low 300
3mm Cutting 45 10 90 high 2"
4mm Cutting 32 10 90 high 2"
Leatherette
/ Engraving 500 10 25 low 300
1.5mm Cutting 100 10 90 high 2"
3mm Cutting 70 10 90 high 2"
Denim
/ Engraving 500 8 8 low 300
1mm Cutting 300 10 90 high 2"
Rubber
/ Stamp Engraving 200 25 60 high 400
2.3mm Cutting 37 10 90 high 2"
Delrin
/ Engraving 500 10 30 low 300
1mm Cutting 140 10 90 high 2"
3mm Cutting 25 10 90 high 2"
5mm Cutting 9 10 90 high 2"
Fiberglass
/ Engraving 500 x x x 300
1mm Cutting 3 10 90 high 2"
Melamine
/ Engraving 500 10 25 low 300
1mm Cutting 38 10 90 high 2"
Mother of Pearl
/ Engraving 500 10 40 low 300
3mm Cutting 113 10 90 high 2"
Paper
/ Engraving 500 10 15 low 300
0.6mm Cutting 300 10 90 high 2"
Mylar
/ Engraving 500 15 20 low 300
1.5mm Cutting 78 10 90 high 2"
Anodized Aluminum
/ Engraving 500 10 40 low 300
Powdercoated Tumblers
/ Engraving 500 10 45 low 300
Ceramic
/ Engraving 500 10 50 low 300
Glass
/ Engraving 500 10 70 low 300
Marble
/ Engraving 500 10 40 low 300
Slate
/ Engraving 500 10 35 low 300
Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Birch Ply
/ Engraving 500 10 10 low 300
3mm Cutting 55 10 90 high 2"
6mm Cutting 25 10 90 high 2"
10mm Cutting 18 10 90 high 2"
15mm Cutting 3 10 90 high 4"
18mm Cutting 2 10 90 high 4"
Cherry Wood
/ Engraving 500 10 20 low 300
3mm Cutting 85 10 90 high 2"
8mm Cutting 24 10 90 high 2"
11mm Cutting 16 10 90 high 4"
15mm Cutting 8 5 90 high 4"
20mm Cutting 5 10 90 high 4"
MDF
/ Engraving 500 10 20 low 300
3mm Cutting 45 10 90 high 2"
10mm Cutting 13 10 90 high 2"
15mm Cutting 5 10 90 high 4"
20mm Cutting x x 90 x 4"
Acrylic
/ Engraving 500 10 10 low 300
3mm Cutting 60 10 90 high 2"
5mm Cutting 30 10 90 high 2"
10mm Cutting 7 10 90 high 2"
15mm Cutting 3 10 90 high 4"
20mm Cutting 2 10 90 high 4"
EVA Foam
/ Engraving 500 5 5 low 300
10mm Cutting 70 10 90 high 2"
20mm Cutting 35 10 90 high 4"
30mm Cutting 15 10 90 high 4"
Cork
/ Engraving 500 5 5 low 300
3mm Cutting 240 10 90 high 2"
Bamboo
/ Engraving 500 10 20 low 300
5mm Cutting 25 10 90 high 2"
Cotton Fabric
/ Engraving 500 10 10 low 300
1mm Cutting 300 10 90 high 2"
3mm Cutting 300 10 90 high 2"
Cardboard
/ Engraving 500 10 20 low 300
3mm Cutting 50 10 90 high 2"
4mm Cutting 45 10 90 high 2"
Leatherette
/ Engraving 500 10 20 low 300
1.5mm Cutting 135 10 90 high 2"
3mm Cutting 100 10 90 high 2"
Denim
/ Engraving 500 5 5 low 300
1mm Cutting 300 10 90 high 2"
Rubber
/ Stamp Engraving 200 25 40 high 400
2.3mm Cutting 50 10 90 high 2"
Delrin
/ Engraving 500 10 20 low 300
1mm Cutting 190 10 90 high 2"
3mm Cutting 30 10 90 high 2"
5mm Cutting 10 10 90 high 2"
Fiberglass
/ Engraving 500 x x x 300
1mm Cutting 5 10 90 high 2"
Melamine
/ Engraving 500 10 20 low 300
1mm Cutting 50 10 90 high 2"
Mother of Pearl
/ Engraving 500 10 30 low 300
3mm Cutting 125 10 90 high 2"
Paper
/ Engraving 500 10 10 low 300
0.6mm Cutting 300 10 90 high 2"
Mylar
/ Engraving 500 10 20 low 300
1.5mm Cutting 85 10 90 high 2"
Anodized Aluminum
/ Engraving 500 10 40 low 300
Powdercoated Tumblers
/ Engraving 500 10 40 low 300
Ceramic
/ Engraving 500 10 30 low 300
Glass
/ Engraving 500 10 60 low 300
Marble
/ Engraving 500 10 40 low 300
Marble
/ Engraving 500 10 30 low 300
Thickness (mm) Processing Speed(mm/s) Min Power(%) Max Power(%) Air pressure value DPI/LENS
Birch Ply
/ Engraving 600 15 15 low 300
3mm Cutting 60 90 90 high 2.5"
6mm Cutting 30 90 90 high 2.5"
10mm Cutting 6 90 90 high 4"
15mm Cutting 3 90 90 high 4"
18mm Cutting 1 90 90 high 4"
Cherry Wood
/ Engraving 600 15 15 low 300
3mm Cutting 88 90 90 high 2.5"
8mm Cutting 25 90 90 high 2.5"
11mm Cutting 18 90 90 high 4"
15mm Cutting 10 90 90 high 4"
20mm Cutting 4 90 90 high 4"
MDF
/ Engraving 600 15 15 low 300
3mm Cutting 75 90 90 high 2.5"
10mm Cutting 12 90 90 high 2.5"
15mm Cutting 4 90 90 high 4"
20mm Cutting 2 90 90 high 4"
Acrylic
/ Engraving 600 15 15 low 300
3mm Cutting 60 90 90 high 2.5"
6mm Cutting 27 90 90 high 2.5"
10mm Cutting 6 90 90 high 4"
15mm Cutting 3 90 90 high 4"
20mm Cutting 2 90 90 high 4"
EVA Foam
/ Engraving 600 15 15 low 300
10mm Cutting 70 90 90 high 4"
20mm Cutting 28 90 90 high 4"
30mm Cutting 16 90 90 high 4"
Cork
/ Engraving 600 15 15 low 300
3mm Cutting 80 10 90 high 2.5"
Bamboo
/ Engraving 600 15 15 low 300
3mm Cutting 25 90 90 high 2.5"
Cotton Fabric
/ Engraving 600 10 10 low 300
1mm Cutting 350 90 90 high 2.5"
3mm Cutting 300 90 90 high 2.5"
Cardboard
/ Engraving 600 15 15 low 300
3mm Cutting 30 90 90 high 2.5"
5mm Cutting 15 90 90 high 2.5"
Leatherette
/ Engraving 600 15 15 low 300
1.5mm Cutting 30 90 90 high 2.5"
3mm Cutting 15 90 90 high 2.5"
Denim
/ Engraving 600 12 12 low 300
1mm Cutting 100 90 90 high 2.5"
Rubber
/ Stamp Engraving 200 90 90 low 300
2.3mm Cutting 55 90 90 high 2.5"
Delrin
/ Engraving 600 10 30 low 300
1mm Cutting 80 90 90 high 2.5"
3mm Cutting 20 90 90 high 2.5"
5mm Cutting 12 90 90 high 2.5"
Fiberglass
/ Engraving x x x x x
1mm Cutting x x x x x
Melamine
/ Engraving 600 30 10 low 300
1mm Cutting 20 90 90 high 2.5"
Mother of Pearl
/ Engraving x x x x x
3mm Cutting 15 90 90 high 2.5"
Paper
/ Engraving 800 10 15 low 300
0.6mm Cutting 150 90 90 high 2.5"
Mylar
/ Engraving 600 20 20 low 300
1.5mm Cutting 20 90 90 high 2.5"
Anodized Aluminum
/ Engraving 600 10 45 high 300
Coated Metals
/ Engraving 600 10 40 high 300
Ceramic
/ Engraving 600 10 30 high 300
Glass
/ Engraving 600 10 25 high 300
Marble
/ Engraving 500 10 45 high 300
Tile
/ Engraving 500 10 45 high 300
